The MZ760 series servo drive user manual provides installation, wiring, operation, panel use, communication and technical specifications.
This manual is intended for users of the MZ760 series servo drives and covers product confirmation, installation, wiring, operation, panel operator usage, communication protocols, and technical specifications. It is suitable for designers, installers, commissioning engineers, and maintenance personnel.
The document includes safety precautions, detailed installation guidelines for both the servo motor and drive, wiring diagrams, MODBUS communication setup, a full list of parameters, and a warranty section. Technical data such as output current, input voltage, control method, and environmental limits are provided in the specifications chapter. This manual is written in Chinese.
| Continuous output current | 4–16 A rms (depending on model) |
|---|---|
| Maximum output current | 14–50 A rms (depending on model) |
| Input voltage (main circuit) | Three‑phase 220 VAC ±10 % / –15 % (50/60 Hz), Single‑phase 85‑265 VAC (50/60 Hz) |
| Control method | SVPWM |
| Feedback encoder | Incremental 2500 P/R or absolute 17 bits single‑turn + 16 bits multi‑turn |
| Operating temperature range | -20 °C to +55 °C |
| Storage temperature range | -25 °C to +55 °C |
| Operating humidity | 5 %–95 % RH (no condensation) |
| Leakage protector type | Fast‑acting leakage protector (do not use delayed type) |
A fast‑acting leakage protector must be used; delayed‑type protectors are prohibited.
No. Direct connection of the servo motor to the mains power is strictly prohibited to avoid damage.
