The MOX Coral II series door station manual provides specifications, functions, and installation guidance for the smart door unit.
The MOX Coral II series door station is a human‑friendly access device featuring a live‑fingerprint reader, high‑definition color camera, and a high‑protection digital keypad. It supports multi‑language operation, audio‑video Ethernet transmission, visual intercom, and various security functions.
The manual details basic and extended functions, technical parameters such as power requirements, CPU, memory, display, and environmental limits, as well as installation options and project case studies for smart community deployments. This manual is written in Chinese.
| Working voltage | 9VDC~26VDC |
|---|---|
| CPU | 1 GHz dual‑core |
| RAM | 1 GB |
| Flash storage | 4 GB |
| Display size | 7 inch capacitive touch screen |
| Screen resolution | 1024 × 600 |
| Installation method | Wall‑mount or recessed |
| Operating temperature | 0 °C ~ 50 °C |
| Relative humidity | 5 % ~ 95 % non‑condensing |
The device operates on a voltage range of 9 VDC to 26 VDC.
It features a 7‑inch capacitive touch screen with a resolution of 1024 × 600.
Yes, it supports both wall‑mount and recessed installation options.
