The manual describes the features, specifications, wiring and usage of Mornsun's TxxxxHL-F series signal conditioning modules.
The TxxxxHL-F series signal conditioning modules provide two‑wire loop power, high‑precision voltage‑to‑current conversion (0.1% FS), and built‑in HART communication. They are housed in a compact SIP9 package (26×9.5×12.5 mm) and operate from –40 °C to +85 °C with isolation up to 2 kV AC.
The document includes product features, selection tables, electrical and mechanical characteristics, EMC compliance, safety instructions, warranty information, and example application circuits for integrating the module with PLC/DCS systems or HART‑enabled field instruments. This manual is written in Chinese.
| Isolation voltage | 2.0 kV AC |
|---|
It provides 2.0 kV AC isolation between input and output terminals.
