The MISUMI B79432 is a 1/2.3" color CMOS camera with USB 3.0 interface, high sensitivity, 4K resolution and selectable LED illumination.
The MISUMI B79432 series is a 1/2.3" color CMOS camera offering up to 4K (3840 × 2160) video at 30 fps via USB 3.0 (Type‑A or Type‑C). It provides multiple illumination options, including white LED and IR LEDs at 850 nm or 940 nm, selectable when ordering.
The camera is driver‑free (UVC) and works with Windows 10, Linux and macOS. It is powered by 5 V DC over the USB connection and operates from –30 °C to 60 °C (storage –10 °C to 45 °C).
| Sensor type | 1/2.3" color CMOS |
|---|---|
| Maximum resolution | 3840 × 2160 @ 30 fps (MJPEG) |
| USB interface | USB 3.0 Type‑A / Type‑C |
| Power source | DC 5 V via USB |
| Storage temperature | -10 °C to 45 °C |
| Lens field of view | 158° (F2.8) |
| LED illumination options | White, IR 850 nm, IR 940 nm |
| Sensitivity | 8300 e / Lux‑sec |
| Dynamic range (SNR) | 73.5 dB @ 8× gain |
It uses a USB 3.0 interface with both Type‑A and Type‑C connectors.
The camera works with Windows 10, Linux and macOS (MAC OSX) using the standard UVC driver.
White LED, IR 850 nm LED, and IR 940 nm LED can be selected when ordering.
It is powered by 5 V DC supplied through the USB connection.
