Overview of the Minleon NEC LED Lighting Controller, its features, interface, and technical specifications.
The Minleon NEC LED Lighting Controller is a network‑enabled device that can drive up to 8,000 RGB channels and supports built‑in lighting effects, DMX‑triggered cues, and custom sequences stored on an SD card. It connects to up to 16 Network Data Boxes (NDBs) and can be linked with multiple NEC units in slave mode for large‑scale installations.
The controller features a two‑line LCD display, a rotary push‑button knob for menu navigation, an onboard audio WAV player, and two optically isolated RJ45 inputs for live DMX triggering. SD cards up to 4 GB per file are supported, and the unit includes a time‑of‑day clock for automatic on/off scheduling.
| Maximum SD card file size | 4 GB per file |
|---|---|
| Addressable RGB channels | Up to 8,000 |
| Network Data Boxes (NDB) supported | 16 via network switch |
| Optically isolated inputs | 2 (RJ45 jacks) |
| Display type | 2‑line LCD with rotating knob |
| Audio playback | Onboard WAV file player with output jack |
| Linking multiple controllers | Supported via slave mode |
The controller supports SD card files up to 4 GB each.
Up to 16 NDBs can be connected via the network switch.
It can address up to 8,000 RGB channels.
The unit provides two optically isolated RJ45 inputs.
