The Micsig OIP350 optical isolation probe user manual provides safety guidelines, specifications, installation, and maintenance instructions.
This manual covers general and repair safety, compliance and environmental information, and detailed descriptions of the probe’s structure, optical‑electrical converters, and connector accessories. It also explains proper installation, connection to oscilloscopes, calibration procedures, and provides application examples.
Technical specifications, maintenance tips, troubleshooting steps, and cleaning instructions are included to help users operate and care for the OIP350 probe safely and effectively. This manual is written in Chinese.
| Bandwidth | 350 MHz |
|---|---|
| Rise Time | ≤ 1 ns |
| Accuracy | 1 % |
| Noise | 1 mV rms |
| Attenuation Ratios (BNC input) | 1X, 10X, 100X |
| Propagation Delay | 15 ns |
| Common‑mode Voltage | 20 kV peak |
| Power Interface | Micsig UPI |
| Optical‑Electrical Converter Size | 8.2 × 2.2 × 3.7 cm |
The probe has a one‑year warranty covering defects under normal use, provided it has not been opened or altered.
Clean the probe with a dry, lint‑free soft cloth or brush; avoid liquids, solvents, and abrasive cleaners. If needed, use a cloth lightly dampened with 75 % isopropyl alcohol and rinse with de‑ionized water.
Always disconnect power and ensure the measured circuit is de‑energized before attaching or removing the probe.
