The manual provides setup, operation, maintenance, and software‑update instructions for the Mercury Marine VesselView 403 multifunction display.
This user manual guides users through the initial setup of the VesselView 403, including the startup screen, setup wizard, and configuration of engine, tank, and trim settings. It also describes the front‑panel buttons, rear‑panel connections, and typical wiring architecture for integration with NMEA 2000 networks.
Additional sections cover routine maintenance such as screen and media‑slot cleaning, electrical‑connection checks, and detailed procedures for updating the software via Wi‑Fi or USB. Safety notices, specifications, and troubleshooting information are also included. This manual is written in Chinese.
| Display resolution | 320 x 240 |
|---|---|
| Display type | LED backlit TFT‑LCD |
| Display size | 104 mm (4.1 in) |
| Viewing angle | 170° |
| Operating temperature | -25 °C to 65 °C |
| Storage temperature | -40 °C to 85 °C |
| Ingress protection | IPX7 |
| Dimensions (W×D×H) | 118 mm × 36.5 mm × 115 mm |
| Weight | 0.32 kg (0.7 lb) |
| Power consumption | 2.2 W (max) |
| Power source | NMEA 2000 |
| Network load equivalent | 4 loads |
