This selection manual introduces the MGC5000 process gas chromatograph, its key features, technical specifications and service options.
The MGC5000 process gas chromatograph is designed for industrial process analysis in sectors such as coal chemistry, natural gas, refining and biopharma. It offers modular circuit design, flexible detector configurations and up to 24 parallel analysis channels.
The document provides company background, product qualifications, detailed technical parameters, and information on remote monitoring, spare‑part support and after‑sales service, helping customers select the appropriate configuration for their application. This manual is written in Chinese.
| Maximum analysis flow routes | 24 |
|---|---|
| Maximum number of components measured | 999 |
| TCD detection limit | 10 ppm |
| FID detection limit | 0.1 ppm |
| FPD detection limit | 10 ppb |
| Operating temperature range | +10 °C ~ +125 °C |
| Temperature control accuracy | ±0.1 °C |
It can operate up to 24 parallel analysis flow routes.
The heating furnace operates from +10 °C to +125 °C with a control accuracy of ±0.1 °C.
