The Magnitude ML-32 nucleic acid extraction instrument user manual provides safety guidelines, specifications, operation steps, maintenance, troubleshooting…
The Magnitude ML-32 is an automated nucleic acid extraction instrument that processes up to 32 samples simultaneously using a rotating magnetic bead method. It features a 32‑bit industrial controller, temperature control, UV disinfection and a touch‑screen interface.
This manual covers safety precautions, environmental requirements, performance specifications, detailed operating procedures, maintenance tasks, transportation and installation instructions, common fault troubleshooting and after‑sales service details. This manual is written in Chinese.
| Operating temperature range | 10 °C – 40 °C |
|---|---|
| Maximum relative humidity | ≤75 % |
| Power supply | AC220 V, 50 Hz, 800 W |
| Sample processing volume | 20 µL – 1000 µL |
| Sample throughput | 1 – 32 samples per run |
| Magnetic bead recovery efficiency | >95 % |
| Heating temperature range | Room temperature to +80 °C |
| Device dimensions (W×D×H) | 500 mm × 500 mm × 490 mm |
| Device weight | 65 kg |
The instrument must be connected to a grounded three‑pin plug, operated only by trained personnel, and users must avoid touching moving parts or exposing the device to water, high temperature, or conductive liquids.
Turn off and unplug the power, then cover the instrument with a soft cloth or plastic bag to protect it from dust.
