Loewe RAP-1580MKII Surround Amplified Processor Owner's Manual

About this manual

The document serves as an owner's manual for the Loewe RAP-1580MKII Surround Amplified Processor. It provides essential safety information, including warnings about electrical shock and proper ventilation, along with specific power requirements for different regions (US/Canada 120V, Europe 230V, China 220V). The manual details the correct use of the main power switch located on the rear panel.

The guide covers installation procedures, including wiring diagrams for various speaker configurations and connections to external devices such as CD players, DVD/Blu-ray players, computers via USB, and radios. It also explains how to set up digital audio inputs (Optical, Coaxial) and HDMI connections. This manual is written in Chinese.

What's inside

• Safety Warnings
• Power Requirements
• Speaker Connections
• Digital Audio Connections
• HDMI Connections
• System Setup Menu
• Speaker Distance Setup
• Network Configuration

Frequently asked questions

What are the power requirements for this amplifier?

The device requires 120V/60Hz in the US and Canada, 230V/50Hz in Europe, and 220V/50Hz in China.

Where is the main power switch located?

The main power switch is located on the rear panel of the device.

What languages does the OSD menu support?

The On-Screen Display (OSD) menu supports English, French, German, Spanish, and Italian.
