The guide explains how to use the LitePoint IQ201X series interconnect test system for Wi‑Fi, WiMAX, Bluetooth, GPS and FM testing.
The LitePoint IQ201X series interconnect test system provides a comprehensive solution for manufacturing test of wireless devices, supporting simultaneous measurement of Wi‑Fi, Bluetooth, WiMAX, GPS and FM signals. It includes a vector signal generator and analyzer, multiple RF ports, and a Windows‑based GUI or C++ API for custom test automation.
This user guide covers system overview, hardware installation, management software, and detailed application chapters for WLAN, Bluetooth, WiMAX, GPS, FM and NFC. It also provides reference waveforms, system requirements, and troubleshooting information. This manual is written in Chinese.
| Operating System | Windows XP Service Pack 2 or later |
|---|---|
| Processor | Intel Pentium dual‑core or equivalent |
| Memory | 1024 MB RAM |
| Hard Disk Space | 500 MB free |
| Screen Resolution | 1024 × 768 |
| Front‑panel RF ports | Four Type N (f) ports |
| VSG WiMAX Frequency Range | 2.15‑2.7 GHz, 3.3‑3.8 GHz, 4.9‑6 GHz |
The system requires Windows XP Service Pack 2 or a later Windows version.
The front panel provides four Type N (f) RF ports for connecting test devices.
The VSG supports WiMAX signals in the ranges 2.15‑2.7 GHz, 3.3‑3.8 GHz and 4.9‑6 GHz.
