The Lightware 18Gbps Matrix Switchers manual provides specifications, features, installation, and operation details for HDMI, DisplayPort and mixed I/O…
Lightware’s 18Gbps Matrix Switchers family delivers high‑bandwidth video routing for HDMI 2.0, DisplayPort 1.2, 4K UHD @ 60 Hz, HDR, Dolby Vision and more. The modular design supports a wide range of input and output formats, advanced EDID management, and seamless integration with control systems.
This manual covers product overviews, technical specifications, installation guidelines, wiring diagrams, control options (RS‑232, Ethernet, USB, web interface), and troubleshooting information for the various MX, UMX, and 25G series models. This manual is written in Chinese.
| Maximum video bandwidth | 18 Gbps |
|---|---|
| Supported video interfaces | HDMI 2.0, HDMI 1.x, DVI 1.0 |
| HDCP support | Cross‑compatible HDCP 2.2 and HDCP 1.4 |
| HDR and Dolby Vision | Supported |
The system can store up to 100 EDID files, offers preset EDID data, and allows editing, uploading (.bin, .dat, .edid) and creating custom EDID files via the software.
All chassis and I/O boards are compatible with HDCP‑protected sources and displays; HDCP can be enabled or disabled per input as needed.
It allows video, audio, control, Ethernet and USB signals to be transmitted over a single fiber, simplifying installation and reducing cost.
