User manual for the Lida-Tech PPC-153T 15.1" industrial tablet, covering specifications, interfaces, power and installation details.
The Lida-Tech PPC-153T is a 15.1‑inch high‑brightness TFT LCD industrial tablet designed for harsh environments (NEMA 4/12, IP65). It features a 1.5‑1.8 GHz CPU, 1 GB RAM, 160 GB storage, and a capacitive touch screen rated for 1 million touches.
The device includes multiple interfaces (4 RS‑232, 4 USB, PCI slot, Ethernet), operates from a 6‑30 V DC supply, and supports MS‑DOS, Windows and Linux operating systems. Dimensions are 408 × 310 × 83 mm and it weighs 7.1 kg. This manual is written in Chinese.
| Resolution | 1024 × 768 |
|---|---|
| CPU speed | 1.5‑1.8 GHz |
| Power consumption | +5 V @ 200 mA |
| Touch life | 1 million touches |
| RS‑232 ports | 4 |
| Dimensions (W×H×D) | 408 × 310 × 83 mm |
| Supported OS | MS‑DOS, Windows, Linux |
The tablet supports MS‑DOS, Windows and Linux operating systems.
