Manual for the Lida-Tech PPC-104A 10.4" industrial tablet PC with specs, interfaces and ordering information.
The PPC-104A is a 10.4‑inch high‑brightness TFT industrial tablet PC featuring a 4‑line resistive touch screen, 800×600 resolution and 85% transmittance. It runs MS‑DOS, Windows and Linux, and the touch panel is rated for one million actuations.
The device includes a 1.6 GHz CPU, 1 GB RAM, 160 GB HDD, and offers extensive I/O: four RS‑232 ports, four USB ports, one Ethernet port, and power input of 9‑30 V DC. Dimensions are 296 × 216 × 77.5 mm and it weighs 2.8 kg. Ordering details and optional accessories are also listed. This manual is written in Chinese.
| Touch screen type | 4‑line resistive |
|---|---|
| Controller interface | USB |
| Power consumption | +5V@200mA |
| Supported OS | MS‑Dos, Windows, Linux |
| Touch life | 1,000,000 touches |
| CPU | 1.6 GHz |
| Power input | DC 9‑30 V |
| RS‑232 ports | 4 |
| Ethernet port | 1 (10/100Base‑Tx) |
The tablet supports MS‑Dos, Windows and Linux.
The touch screen is rated for one million touch cycles.
The device accepts a DC input of 9 to 30 volts.
It provides four RS‑232 ports and four USB ports.
