This is the Chinese safety manual for the Leica DISTO D3a laser distance meter, covering operation instructions, safety warnings, menu settings, and…
The document serves as a safety guide and user instruction manual for the Leica DISTO D3a laser distance meter. It outlines prohibited usage scenarios, such as measuring in explosive environments or directly aiming at the sun, to ensure safe operation.
It provides detailed instructions on starting the device, including battery installation and using the multi-function baseplate. The guide explains how to navigate the menu system to adjust units (meters/feet/inches) and settings like display illumination and beeper status. This manual is written in Chinese.
| Laser Class | Class II |
|---|---|
| Emission Wavelength | 620-690nm |
| Max Emission Power | <1mW |
| Measurement Range | 0.05 m to 100 m |
| Distance Accuracy (2 sigma) | Typical: ± 1.0 mm |
Do not use outside specified ranges, open the casing with tools, or measure near moving machinery without safety facilities.
Select and confirm the 'RESET' function in the menu options.
Error 252 indicates the temperature is too high, and the instrument needs to be cooled down.
