This guide shows how to place, connect, and set up Bluetooth for the Klipsch R-15PM PM2.1BT speaker.
The placement section explains how to mount the R-15PM PM2.1BT speaker on a wall using 1/4" 20‑THREAD brackets, which are not supplied with the product. It lists the required mounting hardware and provides multilingual diagrams for proper positioning.
The connection section details the speaker wiring diagram, Bluetooth® wireless setup, and volume control. It includes screenshots of the Bluetooth pairing process and directs users to Klipsch.com/promedia for additional troubleshooting information. This manual is written in Chinese.
| Mounting thread size | 1/4" 20-THREAD |
|---|
Use a 1/4" 20‑THREAD wall bracket, which is not included with the speaker.
Turn Bluetooth on, select the Klipsch PM2.1BT device in the Bluetooth settings, and the speaker will show as connected.
Visit Klipsch.com/promedia for in‑depth instructions and troubleshooting tips.
