The KETT8188 is a high‑frequency capacitive grain moisture meter that measures up to 12 varieties, auto‑weighs samples, displays results on an LCD, and runs…
The KETT8188 corn moisture meter is designed for rapid, accurate moisture measurement of grains such as corn, wheat, soybeans and more. It automatically measures sample weight, calculates average values, and can handle up to 12 different grain varieties, showing the variety number and a four‑letter abbreviation of the name. The device powers off automatically after about three minutes of inactivity and allows moisture correction within a –9 to +9.9 % range.
Technical specifications include a high‑frequency capacitive measurement principle (50 MHz), a measurement range of 6.0–40.0 % for corn, a standard error of 0.5 % (6.0–20.0 %), LCD display, four AA (5号) batteries as power source, dimensions of 210 × 130 × 190 mm, and a weight of about 1 kg. The instrument operates in ambient temperatures from 0 °C to 40 °C. This manual is written in Chinese.
| Measurement principle | high‑frequency capacitive (50 MHz) |
|---|---|
| Measurement range (corn) | 6.0–40.0 % |
| Standard error (corn) | 0.5 % (6.0–20.0 %) |
| Power source | 4 × AA (5号) batteries |
| Dimensions (H × W × L) | 210 mm × 130 mm × 190 mm |
| Operating temperature range | 0 °C – 40 °C |
It uses a high‑frequency capacitive method at 50 MHz.
It can measure up to 12 different grain varieties.
It is powered by four AA (5号) batteries.
The device measures corn moisture from 6.0 % to 40.0 %.
