JZX Telecom DVER 1.3 Wireless Lighting Control System User Manual

About this manual

The system consists of wireless single‑lamp controllers, field base stations and a central monitoring computer. Communication between devices uses the CWDN cellular wireless data network, with RS‑232 links to the PC software.

Key functions include remote on/off control, status monitoring, energy‑saving scheduling, alarm reporting, and multi‑level routing (up to five hops, each 1000 m). The distributed architecture ensures reliable operation even if individual nodes fail. This manual is written in Chinese.

What's inside

• System Composition
• Communication Method
• Monitoring Software
• Programming Functions
• System Features
• Network Structure
• Installation Overview

Specifications

Frequently asked questions

What wireless technology does the system use?

It uses the CWDN (Cellular+Wireless+Digital+Net) cellular wireless data network.

How many routing levels can the system support?

The system can support up to five routing levels, each up to 1000 m, for a total reach of about 5 km.

How does the monitoring PC communicate with the central controller?

The monitoring software connects to the central coordinator via an RS‑232 serial link.
