This manual explains installation, wiring, operation, and troubleshooting for Jishen CX-M series micro flowmeters.
The CX-M series micro flowmeters from Jishen cover a wide range of flow rates and are suitable for chemicals, water, oil, food, pharmaceuticals and many other liquids. Models CX-M2 to CX-M50 differ in flow range, connection size and material, but share the same basic design and output signal.\n\nThe guide provides product specifications, mechanical drawings, wiring diagrams, step‑by‑step installation instructions, usage precautions, common fault diagnosis and settings for the optional CX DC 8S digital display unit. It also includes selection guidelines and a brief questionnaire for proper model choice. This manual is written in Chinese.
| Flow range (CX-M2) | 0.5~150 mL/min |
|---|---|
| Connection (CX-M2) | G1/8 内螺纹 |
| Medium | 适用于各种化学液体 |
| Temperature range | -30℃到 80℃ |
| Maximum pressure | 32 Bar (customizable) |
| Output signal | 方波脉冲 |
| Supply voltage | 4~26 VDC |
| Material | 不锈钢材质，铝材质 |
