The Jergens Kwik‑Lok® Pins catalog provides selection, ordering information, dimensions, materials, and part numbers for various pin styles.
Jergens Inc. is a world‑leader in specialty fasteners, offering a broad range of Kwik‑Lok® pins that deliver quick, positive engagement and high holding strength for repetitive‑use applications. The catalog presents the full line of pins, including T‑handle, L‑handle, button, recessed, ring‑handle, lifting, and double‑acting designs, each available in aluminum or stainless‑steel constructions.
The document contains detailed selection tables, part numbers, grip‑length options, material specifications, and recommended mounting dimensions. It also lists ordering procedures, lanyard options, and material finishes such as 17‑4‑PH heat‑treated stainless steel and cadmium‑plated alloy steel.
| Standard grip lengths | 1/2" – 6" (10 – 100 mm) |
|---|---|
| Minimum shear resistance (Stainless Steel 17‑4 PH) for 3/16" diameter | 4.75 kN |
Grip length is measured to the edge of the locking ball.
Standard grip lengths range from 1/2" to 6" (10 mm to 100 mm).
Yes, special grip lengths are available on request.
