Technical specifications and features of the Impinj R2000 UHF RFID reader.
The Impinj R2000 is a UHF RFID reader that supports ISO 18000‑6C / EPC Global C1G2 standards and offers multiple connectivity options including USB, RS232, RJ45, Wi‑Fi and Bluetooth. It runs on Windows CE 6.0 and provides an embedded antenna for flexible deployment.
The device operates from 24 VDC (or AC 100‑240 V) power supplies, tolerates a wide temperature range, and is housed in an IP65‑rated enclosure. Detailed technical specifications such as transmit power, I/O configuration, dimensions and environmental limits are provided in the datasheet.
| Supported RFID standards | ISO 18000‑6C / EPC Global C1G2 |
|---|---|
| Transmit power | 1.0 dBm to +30 dBm |
| Supply voltage | 24 VDC (also AC 100‑240 V, 50‑60 Hz) |
| Operating temperature | -20 °C to +50 °C |
| Storage temperature | -40 °C to +70 °C |
| Dimensions (L×W×H) | 214 mm × 136 mm × 32 mm |
| Processor | Marvell PXA 310, 806 MHz |
| Operating system | Windows CE 6.0 |
| Display | 480 × 640 TFT LCD |
| I/O configuration | 4 inputs, 4 outputs, 1 reset, 1 × 5 VDC output |
| Connectivity interfaces | USB console, RS232, USB2.0 host (x2), RJ45, HDMI, Wi‑Fi, Bluetooth, GPS |
| Antenna | Embedded antenna |
It supports ISO 18000‑6C and EPC Global C1G2 standards.
The reader can be powered from a 24 VDC supply or from AC 100‑240 V (50‑60 Hz).
It operates from –20 °C to +50 °C, with a storage range of –40 °C to +70 °C.
The device provides a USB console, RS232, two USB2.0 host ports, RJ45, HDMI, Wi‑Fi, Bluetooth and GPS.
