HYP PM6803A Power Meter User Manual

This manual covers the operation, settings, and communication protocols for the HYP PM6803A single-phase power meter.

HYP PM6803A Power Meter User Manual - cover page
Brand
HYP
Category
Other Electronics
Document type
User Manual
Language
Chinese
Pages
7
File format
PDF
File size
262 KB
Published
14 October, 2026
Updated
14 October, 2026
MD5 checksum
A9D42450A5D0BCAF6A9B87C5F621B917
PDF
HYP PM6803A Power Meter User Manual PDF

About this manual

The HYP PM6803A is a high-end single-phase power meter designed to simultaneously measure and display eight parameters: voltage (VRMS), current (IRMS), peak values for both, active power, apparent power, power factor, and frequency. It features a large LCD screen with adjustable fonts, intelligent testing functions including limit comparisons, and an RS232 interface compatible with the MOBUS CRC16 protocol. This manual is written in Chinese.

What's inside

  • Product Features
  • Technical Specifications
  • Precautions
  • Key Functions
  • Display Icons
  • Setup Menu
  • Common Operations
  • Error Codes
  • Communication Protocol

Specifications

Voltage Range (RMS)0~420.00V
Current Range (RMS)0~3.0000A
Active Power Range999.999W
Voltage Resolution0.01V
Current Resolution0.1mA
Power Resolution1mW
Communication ProtocolMOBUS CRC16

Frequently asked questions

What are the eight parameters measured by this power meter?

It measures voltage, current, peak values for both, active power, apparent power, power factor, and frequency.

How often should the device be calibrated?

It is recommended to calibrate the power meter once a year.

What does error code Err003 indicate?

Err003 indicates an error reading data from the acquisition board, requiring contact with sales or the manufacturer.

What is the maximum voltage difference allowed between the test circuit and the meter case?

The voltage difference must not exceed DC2KV to ensure safety and prevent damage.

Download PDF (262 KB)
