Huazhong HNC-8 Five-Axis CNC System User Manual

User manual for the Huazhong HNC-8 five‑axis CNC system covering setup, programming, and maintenance.

Huazhong HNC-8 Five-Axis CNC System User Manual - cover page
Brand
Huazhong
Category
Industrial Robot
Document type
User Manual
Language
Chinese
Pages
165
File format
PDF
File size
4.7 MB
Published
28 September, 2026
Updated
28 September, 2026
MD5 checksum
18A0305BA8A354976D5DB393137C5494
PDF
Huazhong HNC-8 Five-Axis CNC System User Manual PDF

About this manual

This manual provides a comprehensive guide to the Huazhong HNC-8 five‑axis CNC system, including system architecture, command functions, and program‑assistance features. It also details PLC integration, turning‑milling composite functions, and key parameter settings.

The document includes calibration procedures, dynamic accuracy testing, and RTCP (real‑time coordinate processing) configuration, helping users achieve precise machining and efficient workflow on five‑axis machine tools. This manual is written in Chinese.

What's inside

  • Foreword
  • Five-Axis Machine Tool Processing Features
  • Five-Axis CNC Machine Structure
  • Five-Axis Command Functions
  • Program Assistance Functions
  • Turning‑Milling Composite Functions
  • Parameter Description
  • PLC Introduction
  • Key Explanations
  • Appendices

Specifications

Recommended feed speed for dynamic accuracy testing1000 mm/min
Dynamic accuracy mismatch tolerance≤ 1.5 µm

Frequently asked questions

What does RTCP mean in the HNC-8 system?

RTCP is a true five‑axis algorithm that allows programming in workpiece coordinates without needing to consider the machine’s kinematic chain.

What feed speed is recommended for dynamic accuracy tests?

A feed speed of 1000 mm/min is recommended.
