The manual explains installation, operation, safety and technical specifications of the HYCTDW current‑transformer short‑time thermal current test device.
This document provides a complete guide for the HYCTDW current‑transformer short‑time thermal current test device, covering its features, hardware architecture, installation steps, software operation, and remote control. It also includes safety warnings and detailed technical parameters to ensure accurate and safe testing.
The manual describes how to connect the power supply, configure the electric‑adjustable regulator and high‑current generator, operate the software for data acquisition and analysis, and perform remote control via Ethernet. Users are instructed on proper grounding, safe distances, and maintenance procedures. This manual is written in Chinese.
| Maximum output current | 0~10000 A |
|---|---|
| Output current error | <10 % of set value |
| Output capacity | 250 kVA |
| Sample loop current measurement range | 0~10000 A |
| Sample loop current measurement error | 0.1 % FS |
| Sample loop voltage measurement range | 0~30 V |
| Sample loop voltage measurement error | 0.1 % FS |
| Sampling rate | 25 kHz |
| Time measurement error | 0.04 ms |
| Power supply | AC 380 V, 45‑65 Hz |
| Operating temperature | 0~50 °C |
| Maximum humidity | <90 % |
The device can output up to 10 000 A.
Operators must keep at least a 3 meter safety distance from the regulator and the high‑current generator.
It requires an AC 380 V supply at 45‑65 Hz.
Yes, it can be operated via Ethernet using a remote PC that logs into the control box’s industrial PC.
