The Hotone Binary IR Cab User Manual explains setup, operation, and technical specifications for the IR cabinet simulator.
The Binary IR Cab is an IR‑based cabinet simulator that includes 100 built‑in guitar/bass cabinet models, 8 power‑amp simulations, and 10 microphone simulations. It features a dual‑DSP platform, CDCM modeling, a clear OLED display, and a range of input and output connectors for flexible use.
The manual covers panel layout, connection methods, preset navigation, bypass/mute functions, parameter editing, and provides detailed IR, power‑amp, and microphone model tables along with full technical specifications. This manual is written in Chinese.
| Audio resolution | 24‑bit |
|---|---|
| Signal‑to‑noise ratio | up to 110 dB |
| Sample rate | 48 kHz |
| Frequency response | 20 Hz‑20 kHz |
| Power supply | 9 V DC, center‑negative polarity |
| Current consumption | minimum 200 mA |
| Dimensions (L×W×H) | 121 mm × 72 mm × 47 mm |
| Weight | 340 g |
| Input impedance | 1 MΩ |
| Output impedance | 100 Ω |
| Number of presets | 100 (10 groups × 10 presets) |
It supports 100 presets, organized as 10 preset groups with 10 presets each.
Press both footswitches (▽/△) simultaneously; the display will show “BYPASS”.
It requires a 9 V DC power source with center‑negative polarity.
The PHONES jack is a 1/4‑inch (6.35 mm) stereo connector for headphones.
