This manual details the operation, settings, and functions of the Hi-Target HDL All-Star radio, covering modes like external radio, relay, and network relay…
The Hi-Target HDL All-Star radio is a multifunctional device designed for high-precision GNSS measurement data transmission. It supports three primary working modes: external radio, radio relay, and network relay, ensuring reliable data links for base stations and mobile stations. The device features a built-in 30W transceiver module and a 4G network communication module for extended range and cost-effective CORS data sharing.
The manual provides instructions on operating the device via physical buttons or the Hi-Radio software. Key topics include power requirements (12V/20AH), safety precautions regarding radio frequency exposure, and detailed configuration steps for different working modes. Technical specifications cover frequency ranges, transmission power, GPS positioning accuracy, and environmental ratings. This manual is written in Chinese.
| Transmission Power | High (30W), Low (10W) |
|---|---|
| Frequency Range | 457-467MHz; 223.025 -235MHz (optional) |
| Airborne Baud Rate | 9600 /19200 bps |
| GPS Positioning Accuracy | <2.5 meters |
| Power Supply Requirement | 12V/20AH or higher |
| Operating Temperature | -40 ~ 65°C |
| Dimensions | 180*115*86 mm |
The three main working modes are external radio, radio relay, and network relay.
It is recommended to keep the distance between the operator and the antenna at least 2 meters to reduce harm from high-energy radio waves.
The radio supports China Mobile 4G/3G/2G, China Unicom 4G/3G/2G, and China Telecom 4G networks.
