User manual for the GZM GZM-6024D and GZM-6032D mixing consoles with setup, operation, and technical specifications.
This manual provides a quick guide, wiring diagrams, and detailed explanations of all functions and controls for the GZM-6024D and GZM-6032D mixing consoles. It includes safety information, connection instructions for microphones, line inputs, USB, and auxiliary outputs, as well as network control options.
Technical parameters such as input sensitivity, output voltage, THD, EQ settings, and network connectivity are listed, helping users configure the console for optimal performance in live or studio environments. This manual is written in Chinese.
| Input sensitivity (MIC) | -60 dB |
|---|---|
| Input sensitivity (LINE) | -50 dB |
| Maximum output voltage | 3 V |
| THD | <0.03% (1 kHz Full Power) |
| Electronic gain | -32 dB to 10 dB |
| Input impedance (MIC) | >5 kΩ |
| Input impedance (LINE) | >10 kΩ |
| Signal‑to‑noise ratio | >85 dB |
| Frequency response | 20 Hz – 20 kHz ±1 dB |
| Parametric EQ (input) | 5 bands ±12 dB |
| Parametric EQ (output) | 15 bands ±12 dB |
| Output delay | 0–30 ms |
| Threshold ratio | +6 dB to -50 dB |
| Attack/Release time | 1–127 ms |
| Power supply | AC 110‑250 V, 50‑60 Hz |
The MIC input sensitivity is –60 dB.
Yes, use the fast Ethernet (100 Mb/s) port with a CAT5 cable to connect to a PC or wireless router and control via the T20 app or Windows software.
