The D-MNSV6-X16 magnetic navigation sensor user manual provides safety instructions, installation steps, interface specs, and troubleshooting for AGV systems.
This manual explains safe handling and installation of the D-MNSV6-X16 magnetic navigation sensor, including warnings about explosive or flammable environments, required qualified personnel, and proper mounting using non‑magnetic materials. It also details the sensor’s power connections, wiring colors, and recommended cable specifications.
The document describes the sensor’s communication options (RS‑232, RS‑485, CAN, MODBUS‑RTU), configuration procedures via PC software, and provides a full list of technical specifications such as input voltage, current, operating temperature, and IP54 protection rating. Warranty information and after‑sales service terms are also included. This manual is written in Chinese.
| Input voltage | DC 9‑28 V |
|---|---|
| Rated current | 95 mA |
| Communication interfaces | RS‑232 / RS‑485 / CAN |
| Baud rate | 115200 bps |
| Magnetic point spacing | 10 mm |
| Protection rating | IP54 |
| Operating temperature | -20 °C to +80 °C |
| Operating humidity | ≤ 80 % RH |
| Storage temperature | -25 °C to +70 °C |
| Storage humidity | ≤ 85 % RH |
| Enclosure material | Aluminum alloy |
| Filling material | Silicone |
The sensor supports RS‑232, RS‑485, CAN, and MODBUS‑RTU protocols with a baud rate of 115200 bps.
The product comes with a one‑year limited warranty from the date of sale.
