GreenPower Lighting GPL LED V1.0 Animation Settings User Manual

This user manual explains how to configure animation effects in the GPL LED V1.0 software for GreenPower Lighting systems.

GreenPower Lighting GPL LED V1.0 Animation Settings User Manual - cover page
Brand
GPL
Category
lighting LED
Document type
User Manual
Language
Chinese
Pages
30
File format
PDF
File size
9.2 MB
Updated
29 September, 2026
MD5 checksum
228F06BABBA56D457DF51AE2327614FF
PDF
GreenPower Lighting GPL LED V1.0 Animation Settings User Manual PDF

About this manual

The manual provides step‑by‑step instructions for creating and editing animation sequences with the GPL LED V1.0 software. It covers the purpose of each animation type, required parameters, and how to save the resulting files for use with GreenPower Lighting control hardware.

The document includes a full list of supported effects—Flash, Searchlight, Shutter, Concentric Circle, Vertical, Horizontal, Scan, Rain, Random, Slope, Clockwise/Anti‑Clockwise, as well as file import/export procedures for BMP, OBK and other formats. Contact information for technical support is also provided. This manual is written in Chinese.

What's inside

  • Preface
  • Animation Types Overview
  • Flash Effect
  • Searchlight Effect
  • Shutter Effects
  • Concentric Circle Effects
  • File Import and Export

Specifications

Software versionV1.0
Maximum upload file size2 M or 8 M
Supported file extensions.owh, .owb, .bin, .obk, .bmp

Frequently asked questions

How can I import a BMP file into GPL LED?

Use the ACTION editor to open a BMP file and import it; the BMP image must match the size requirements of GPL LED.

How do I set the number of searchlight beams?

In the Searchlight settings, specify the desired number of beams under “設定探照燈數量”.

Who holds the copyright for this software?

The copyright belongs to GreenPower Lighting CO., LTD.
