Fuling FS110 AC Servo System User Manual

The Fuling FS110 AC servo system user manual provides safety guidelines, installation, wiring, operation, troubleshooting and specifications.

Fuling FS110 AC Servo System User Manual - cover page
Brand
Fuling
Category
Industrial Robot
Document type
User Manual
Language
Chinese
Pages
39
File format
PDF
File size
2.9 MB
Published
04 October, 2026
Updated
04 October, 2026
MD5 checksum
61CA4DC717F5BB4646EA09DEB6E280EC
PDF
Fuling FS110 AC Servo System User Manual PDF

About this manual

This manual covers the FS110 series AC servo system, including safety precautions, product overview, installation and wiring instructions, display functions, operation procedures, parameter tables and troubleshooting steps. It also lists the system’s technical specifications and cable naming conventions.

The document is intended for engineers and technicians who install, commission, and maintain the servo drive and motor, offering detailed wiring diagrams, signal definitions, and recommended environmental conditions. This manual is written in Chinese.

What's inside

  • Safety and Precautions
  • Product Overview
  • Installation and Wiring
  • Display and Operation
  • Operation
  • Parameter Table
  • Troubleshooting
  • Product Specifications
  • Cable Naming Rules

Specifications

Input voltage220 V AC 1‑Phase, 50/60 Hz
Maximum currentup to 39 A
Input voltage levels1‑110 V, 2‑220 V, 4‑380 V

Frequently asked questions

What input voltage options are supported by the FS110 series?

The FS110 series can be powered from 1‑110 V, 2‑220 V or 4‑380 V AC input levels.

What is the maximum current rating for the 2 kW model?

The 2 kW version of the FS110 can draw up to 39 A of current.
