Instruction manual for assembling, installing, and operating the FELIX Sport Jet RC model.
The FELIX Sport Jet instruction manual provides step‑by‑step guidance for building the aircraft, including fuselage, air‑intake, wing, control surface, servo, turbine, fuel tank, canopy, and retract assemblies. It also contains safety warnings and a liability disclaimer.
Additional sections cover recommended component specifications such as servo torque, turbine models, CG position, and servo throw limits, as well as optional accessories like an extra fuel tank and extension cables.
| Recommended CG position | 460 mm |
|---|---|
| Recommended turbine models | K85G (standard), K100G (sport), K120G (F3S) |
| Minimum servo torque | 10 kg·cm |
| Optional fuel tank capacity | 3 L |
| Recommended servo throw movement | Aileron ±15 mm, Elevator ±20 mm, Rudder ±35 mm |
FELIX disclaims all liability for loss, damage, personal injury, or any other direct or indirect damages arising from the use or assembly of the model.
The manual recommends a center‑of‑gravity position of 460 mm as a starting point.
K85G is suggested for standard flights, K100G for sport flights, and K120G for F3S flights.
