The ESP32 datasheet provides pin configurations, electrical characteristics, package details, and integrated Wi‑Fi/Bluetooth specifications.
The ESP32 is a high‑performance microcontroller with integrated 2.4 GHz Wi‑Fi and Bluetooth. The datasheet lists the pin‑out, power supply ranges, and the optional PSRAM and flash configurations.
Detailed sections cover the RTC, ADC, UART, SDIO interfaces, as well as the various development kits and mesh modules that use the ESP32. Package information and mechanical drawings are also included. This manual is written in Chinese.
| Operating voltage | 1.8 V to 3.6 V |
|---|---|
| Crystal frequency | 40 MHz ±10 ppm |
| Flash memory type | SiP Flash (optional PSRAM‑3V3) |
| Package | 5 mm × 5 mm QFN |
The ESP32 operates from 1.8 V up to 3.6 V.
It uses SiP Flash, with an optional 3.3 V PSRAM module.
The reference crystal runs at 40 MHz with a tolerance of ±10 ppm.
The module is packaged in a 5 mm × 5 mm QFN package.
