The CPS500 is a compact multi‑axis positioning controller with a 7" touch screen, supporting 1‑6 axes and various I/O and fieldbus options.
The CPS500 from esitron‑electronic is a compact positioning system designed for 1 to 6 linear or rotary axes. It features a 7" wide‑screen TFT display, integrated PLC functions, and a variety of digital and analog inputs/outputs. The controller runs on 24 VDC and includes built‑in non‑volatile memory for parameters and programs.
The unit offers extensive communication options such as CANopen, Ethernet, USB and RS‑232, and can be expanded with up to seven modular I/O extensions. Special functions support rotary tables, indexing attachments, hydraulic drives, and automatic clamping, making it suitable for a wide range of automation and positioning applications.
| Supply voltage | 24 VDC / 0.2 A (unloaded) |
|---|---|
| Dimensions (W×H×D) | 213 mm × 160 mm × 33 mm |
| Digital inputs | 10 × 24 VDC |
| Digital outputs | 8 × 24 VDC, 0.5 A, short‑circuit proof |
| Analog inputs | 2 × 12‑bit (0‑10 V / 0‑20 mA / ±10 V) |
| Analog outputs | 2 × 0‑10 V, 10‑bit, max 5 mA |
| Operating temperature range | 0 °C to 50 °C |
| Supported axes | 1 to 6 axes (linear and rotary) |
The CPS500 can control from one up to six linear or rotary axes.
The unit operates from a 24 VDC supply, drawing about 0.2 A when no modules are attached.
