Catalog of EPC 260 series optical encoders with specifications, model options and application notes.
The EPC 260 series is an optical incremental encoder designed for industrial environments. It offers a compact form factor, selectable pole counts and a range of voltage and IP ratings.
The document lists mechanical dimensions, electrical parameters, resolution options and compatible shaft sizes for the 260 model and many other EPC encoder families. Contact information for the SUNSTAR distributor is provided at the end. This manual is written in Chinese.
| Operating voltage | 5‑28 VDC |
|---|---|
| Maximum frequency | 200 kHz – 300 kHz |
| Resolution options (CPR) | 200‑2540 |
The encoder can be powered from 5 VDC up to 28 VDC.
