The Enbia EB322S digital audio decoder board software manual provides specifications, pin assignments, and usage instructions.
This manual describes the EB322S digital audio decoder board, its supported audio formats, sample rates, bit depth, and available display options. It also lists the hardware interfaces such as USB, RDS and the various display types (VFD, LCD, LED).
The document includes detailed pin‑out tables, power‑supply requirements, current consumption figures, and example schematic designs for LED and demo boards. It serves as a reference for integrating the decoder into audio systems and for troubleshooting the board’s functions. This manual is written in Chinese.
| Supported Audio Formats | Dolby Digital, Dolby Digital EX, DTS, DTS‑ES, HDCD, Prologic II |
|---|---|
| Output Sample Rate | 192 kHz |
| Display Types | VFD, LCD, LED |
| Current Consumption | 400 mA (typ), 500 mA (max) |
It supports Dolby Digital, Dolby Digital EX, DTS, DTS‑ES, HDCD and Prologic II.
The decoder accepts a 96 kHz input and provides a 192 kHz output with 24‑bit resolution.
The board can drive VFD, LCD or LED displays.
