The manual provides setup, wiring, operation, and safety instructions for the East Rong smart high‑speed infrared spherical camera.
This document describes the features, technical specifications, and configuration steps for the smart high‑speed infrared spherical camera. It covers product overview, technical parameters, DIP‑switch address and protocol settings, wiring diagrams, alarm connections, installation guidelines, and detailed operation procedures.
Safety precautions, maintenance tips, and an address‑code reference table are also included to ensure reliable and safe deployment of the camera in various indoor and outdoor environments. This manual is written in Chinese.
| Power supply | DC12V ±5% |
|---|---|
| Power consumption | 40W |
| Communication interface | RS485 bus |
| Baud rates | 1200/2400/4800/9600 bps |
| Horizontal rotation speed | 0.4°‑100° per second |
| Horizontal rotation range | 360° unlimited |
| Tilt rotation speed | 0.4°‑100° per second |
| Tilt range | 0°‑90° |
| Alarm input ports | 4 |
| Alarm relay output | 1 (normally closed) |
| Operating temperature (indoor) | 0 °C – +40 °C |
| Operating temperature (outdoor) | -40 °C – +60 °C |
| Maximum humidity | ≤95% non‑condensing |
| Lens | SONY 18× optical zoom (color/black‑white) |
| Minimum illumination | 0.7 Lux (day) / 0.002 Lux (night) |
| Video signal output | 1.0 ± 0.2 Vpp |
The camera supports 1200, 2400, 4800, and 9600 bps.
