E-Z-GO 295cc and 350cc 4-Cycle Engine Shop Rebuild and Parts Manual

About this manual

This manual is intended for mechanics working on E‑Z‑GO 4‑cycle engines of 295 cc and 350 cc displacement. It guides users through engine disassembly, detailed measurements, specifications, and reassembly, with illustrated parts breakdowns and required tool lists.

The document includes sections on engine and crankcase disassembly, torque specifications, cylinder‑head assembly, service tools, and warranty information, making it a comprehensive reference for rebuilding and servicing these engines.

What's inside

• Engine Disassembly
• Crankcase Disassembly
• Engine Measurements and Specifications
• Crankcase Assembly
• Cylinder Head Assembly
• Illustrated Parts Breakdown
• Service Tools
• Limited Warranty

Frequently asked questions

What warranty coverage does the engine have?

The engine is covered by a two‑year limited warranty on emission‑control parts.

What tools are required for engine measurements?

Required tools include calipers, a depth gauge, a feeler gauge set, a telescoping gauge set, and micrometers of 1", 2" and 3".
