The ISI‑Fixture test board from DisaiKang Technology supports multi‑rate loss testing up to 16 Gbps with high‑precision impedance and low skew.
The ISI‑Fixture high‑speed test board is designed for multi‑rate loss applications, supporting 8 Gbps (4 GHz), 12.5 Gbps (6.25 GHz) and 16 Gbps (8 GHz). It offers excellent differential impedance consistency (100 Ω ± 5 %), ultra‑low insertion loss, channel skew under ±2 ps, and SMA connectors with up to 40 GHz bandwidth.
The board provides 16 sets of loss lines ranging from 3000 mil to 30000 mil, a mechanical size of 376 mm × 249 mm, and has been validated using a Keysight E5071C network analyzer (300 kHz–20 GHz). The document details application scenarios, key features, design considerations, and test results. This manual is written in Chinese.
| Supported data rates | 8 Gbps (4 GHz), 12.5 Gbps (6.25 GHz), 16 Gbps (8 GHz) |
|---|---|
| Differential impedance | 100 Ω ± 5 % |
| Channel skew variation | ±2 ps |
| SMA connector bandwidth | up to 40 GHz |
| Loss line lengths | 16 groups from 3000 mil to 30000 mil |
| Board dimensions | 376 mm × 249 mm |
| Test instrument used | Keysight E5071C (300 kHz–20 GHz) |
It supports 8 Gbps (4 GHz), 12.5 Gbps (6.25 GHz) and 16 Gbps (8 GHz).
The SMA connector can handle up to 40 GHz bandwidth.
There are 16 groups of loss lines ranging from 3000 mil to 30000 mil.
The board measures 376 mm by 249 mm.
