Technical data sheet for the LD6046 and LD6047 automobile semiconductor devices, including pinout, electrical characteristics and application notes.
The LD6046 and LD6047 are automobile‑grade semiconductor devices offered in DIP8 and SOP8 packages. The document provides the pin configuration, recommended operating voltage range, and key electrical parameters such as resistance and capacitance values.
Typical application circuits, performance tables, and package dimensions are included to help designers integrate the parts into automotive electronic systems. The data sheet also lists test conditions and tolerance specifications for reliable operation in harsh vehicle environments. This manual is written in Chinese.
| Package | DIP8, SOP8 |
|---|---|
| Operating Voltage | 7.0 V ~ 16 V |
| VBatt (Battery voltage) | 13.5 V |
Both devices are offered in DIP8 and SOP8 packages.
The devices operate from 7.0 V up to 16 V.
