User manual for Crossbow MTS/MDA sensor boards covering specifications, wiring, and operation of the various sensor modules.
The Crossbow MTS/MDA Sensor Board User Manual provides detailed information on the MTS series sensor boards and MDA series data‑acquisition boards that interface with Crossbow MICA wireless motes. It describes each board variant, the supported sensors, and how to connect and configure them.
The manual also includes schematics, conversion formulas, prototyping area pinouts, and warranty and support details, helping developers integrate the boards into their wireless sensor networks.
| Thermistor type | YSI 44006 |
|---|---|
| Thermistor time constant | 10 seconds, still air |
| Thermistor base resistance | 10 kΩ at 25 °C |
| Thermistor repeatability | ±0.2 °C |
| Light sensor type | Clairex CL94L |
| Light sensor off resistance (ROFF) | 520 kΩ |
| ADXL202JE G‑range | ±2 G |
| ADXL202JE bandwidth | DC‑50 Hz |
| ADXL202JE resolution | 2 mG RMS |
Digital control signal PW1 must be turned on to power the light sensor.
Crossbow provides a one‑year warranty from the date of shipment.
