The CoolDrive CDS7L servo drive user manual provides safety guidelines, installation, wiring, configuration, operation, and maintenance instructions.
This manual covers the complete lifecycle of the CoolDrive CDS7L servo drive, including safety precautions, installation requirements, wiring diagrams, parameter settings, and troubleshooting. It also details the drive's functional specifications, communication interfaces, and supported safety functions such as STO.
The document is organized into sections on foreword, installation, wiring, settings, operation, control block diagrams, adjustment, application functions, monitoring, maintenance, and safety features, providing clear step‑by‑step guidance for technicians and end users. This manual is written in Chinese.
| Continuous output current | 1.5‑30 A (varies by model) |
|---|---|
| AC input voltage | 20 V‑240 V, –15% ~ +10% (single‑phase or three‑phase) |
| Power consumption | 7‑25 W depending on model |
| Cooling method | Fan forced cooling |
| Protection rating | IP20 |
Power must be turned off for at least 10 minutes and the CHARGE indicator must be off before any wiring or inspection work.
