The Conet ModuCon Remote is a compact interface system that enables remote PLC monitoring and control via cellular networks, with email alerts and web I/O…
ModuCon Remote connects to PLCs such as Mitsubishi and Omron and uses the KDDI cellular network to provide remote monitoring, ladder changes, and I/O control without needing a dedicated LAN line. It offers email alerts, browser‑based I/O status, and a Linux‑based platform for custom applications.
The device includes a built‑in CDMA/1x communication module, 4 digital inputs and outputs, low power consumption (~4 W), and a lightweight design (≈238 g). It supports Ethernet, RS‑232C, USB, and can be powered from an AC adapter. Pricing plans for the communication service are also provided. This manual is written in Japanese.
| Input voltage | DC12V–DC24V |
|---|---|
| Power consumption | ≈4 W (excluding USB device) |
| Dimensions (W×D×H) | 160.2 mm × 82 mm × 26 mm |
| Weight | ≈238 g (without antenna) |
| Downlink speed | max 144 kbps |
| Uplink speed | max 64 kbps |
| Operating temperature | 0 °C – 40 °C |
It monitors the PLC’s DI ports and sends an alert email to a PC or mobile phone when a fault is detected.
Yes, an optional serial converter allows remote operation of PLCs without an Ethernet unit.
It uses a KDDI CDMA/1x communication module (WM‑M200) with 99.9 % population coverage.
