Chieftek Ironless & Iron Core Linear Motor Installation Guide

About this manual

This guide provides detailed instructions for installing Chieftek's ironless and iron core linear motors. It includes safety notices, handling precautions, and step‑by‑step procedures for both motor types, as well as system assembly diagrams and surface tolerance requirements.

Additional sections cover electrical safety, cable management, temperature sensor information, and warranty details. Appendices contain performance graphs and temperature‑sensor data for reference.

What's inside

• How to Use This Guide
• Ironless Motor Installation
• Safety Notice
• Installation Notice for Ironless Linear Motor
• System Assembly Diagram
• Installation Surface Tolerances
• Installation Steps (Ironless)
• Ironcore Motor Installation
• Appendix

Specifications

Frequently asked questions

What safety precaution is required regarding strong magnetic fields?

Do NOT carry any soft magnetic objects within 30 cm of the stator.

What is the warranty period for the linear motor?

Chieftek provides a one‑year warranty from the ex‑work date.

What power source is used for the linear motor and what precautions are needed?

The linear motor is powered by a servo drive; ensure proper grounding and avoid uncontrolled movements by cutting power before maintenance.
