This manual describes safety, structure, routine maintenance and environmental requirements for the D3P-1100-P0 robot.
The document provides detailed instructions for daily maintenance and troubleshooting of the D3P-1100-P0 robot, aimed at assembly, commissioning and service engineers. It covers safety symbols, required personnel qualifications, and procedures for safe operation.
Key sections include safety maintenance, robot key structure and disassembly, routine maintenance tasks, and environmental conditions. The manual also explains emergency‑stop operation, safety markings, and recommended inspection intervals to ensure reliable robot performance. This manual is written in Chinese.
| Operating Temperature Range | -10 °C to 50 °C |
|---|---|
| Relative Humidity Range | 20 %–80 % RH (no condensation) |
| Maximum Installation Altitude | 0 m to 3000 m |
| Dust and Water Protection | IP53/54 (dust ingress below functional level, water splash protection) |
Only personnel who have received industrial‑robot training, possess relevant knowledge and experience, and have read the manual are permitted to install, commission, or service the robot.
