Changhai SWP-ASR100 Series Paperless Recorder User Manual

About this manual

The document serves as a user guide for the Changhai SWP-ASR100 series color paperless recorders. It details product features, data storage methods, alarm types, and output configurations to assist users in understanding device capabilities and troubleshooting issues.

The manual provides comprehensive instructions on installation environments, terminal descriptions, and wiring procedures. It also explains how to operate the device, navigate display screens, configure system parameters via menus, set up communication protocols (such as SWPP and MODBUS RTU), and perform routine maintenance tasks like battery replacement. This manual is written in Chinese.

What's inside

• Product Overview
• Installation and Wiring
• Operation Instructions
• Display Screen Explanation
• Configuration Settings
• Communication Protocols
• Model Spectrum Table
• Daily Maintenance

Frequently asked questions

What safety precaution is required regarding the power supply before cleaning or operating the instrument?

You must disconnect the power before plugging in or removing communication cables, and you should turn off the power before wiping the surface.

What is the specific voltage hazard if the instrument is wired incorrectly or not grounded?

If wiring is incorrect or the ground wire is missing, the casing may carry approximately 110 volts while operating.

What type of cleaning agents are prohibited for maintaining the instrument surface?

You must not use gasoline, alcohol, banana water, or other organic solvents to clean the instrument.
