The Castrol Hysol NB cutting fluid is a high‑performance semi‑synthetic metalworking fluid without chlorine or boron, suitable for cast iron and low‑alloy…
Hysol NB is a semi‑synthetic metalworking fluid designed for large central systems and single‑tank machines. It is especially suited for machining cast iron and low‑alloy steel, providing excellent surface finish and stability.
Key benefits include low foam, superior corrosion protection, advanced lubrication, and good wetting properties. For optimal performance, store the product in sealed containers, keep it in a cool dry place away from sunlight, and maintain the recommended water hardness of 100‑700 ppm CaCO₃. This manual is written in Chinese.
| Appearance (concentrate) | Amber |
|---|---|
| Appearance (solution) | Transparent |
| pH (4% solution) | 9.4 |
| Refractive Index | 2.3 |
| Recommended concentration for grinding | 7‑8% |
| Recommended concentration for general machining | 8‑10% |
| Recommended water hardness | 100‑700 ppm CaCO₃ |
Hysol NB is especially suitable for machining cast iron and low‑alloy steel.
No, it is a high‑performance fluid without chlorine or boron.
Keep the container sealed, store in a cool dry place away from sunlight, preferably indoors.
The recommended concentration for grinding is 7‑8%, and 8‑10% for general machining.
