Carlsbro CSD120/CSD130 Digital Drum Set User Manual

About this manual

This user manual covers the assembly of the Carlsbro CSD120/CSD130 digital drum set, including the drum stand, pads, cymbals, module, and bass drum. It details how to connect the instrument to external devices such as audio systems, phones, MP3 players, PCs, and MIDI keyboards. The guide also explains how to power the unit safely and adjust settings to avoid electrical interference.

What's inside

• Assembly
• Module function
• Connect with external devices
• Operation
• Record and replay
• Set up
• Reset setting
• MIDI setting
• Trouble shooting
• Drum kit list

Frequently asked questions

What conditions should be avoided to prevent damage to the digital drum set?

Do not expose the unit to direct sunlight, high temperatures, or move it while cables are connected.

How many cable ties are required to secure the pad cables?

You must use 12 cable ties to tie the cables.

What is the angle required when setting the three master tubes during assembly?

The three master tubes must be set at a 120 degree angle.
