Technical specifications, dimensions, and approvals for Carlo Gavazzi inductive proximity sensors (2‑wire, 3‑wire and analogue versions).
The document provides detailed data for Carlo Gavazzi inductive proximity sensors, covering 2‑wire DC, 3‑wire DC and analogue‑output variants. Both flush‑mountable and non‑flush‑mountable designs are listed with their mechanical dimensions and electrical characteristics.
Key specifications include sensing distances from 1 mm to 22 mm, operating frequencies between 500 Hz and 2 kHz, rated supply voltages of 10‑40 VDC, IP67 protection, and a range of output types (NPN‑NO, PNP‑NO, NPN‑NC, PNP‑NC). Approvals such as CE, UL and CS are also documented.
| Thread size | M8 x 30 |
|---|---|
| Operating frequency | 2 kHz |
| Sensing distance | 2.0 mm |
| Rated supply voltage | 10‑30 VDC |
| Mounting type | Flush and Non‑Flush |
| Output contact types | NPN‑NO, PNP‑NO, NPN‑NC, PNP‑NC |
The M8 × 30 sensor has a sensing distance of 2.0 mm.
Both flush‑mountable and non‑flush‑mountable versions are offered.
The sensors are available with NPN‑NO, PNP‑NO, NPN‑NC and PNP‑NC contacts.
