The Brinno TLC200 Pro user manual provides setup steps, optional accessories, settings, and specifications for the HDR time‑lapse camera.
This manual introduces the Brinno TLC200 Pro HDR time‑lapse video camera, covering package contents, basic operation, and power‑saving features. It guides users through first‑time setup, selecting capture modes, and adjusting image quality, white balance, and HDR settings.
Later sections detail optional accessories, battery life expectations, and full technical specifications such as sensor type, lens optics, storage options, and dimensions. Contact information and support links are also provided.
| LCD Screen | 1.44" TFT LCD |
|---|---|
| Lens Rotating Angle | 120° |
| Waterproof | Optional (requires ATH120 housing) |
| Capture Mode | Time Lapse (auto generation) |
| Sensor Type | 1/3" HDR sensor |
| Dynamic Range | 115 dB |
| Resolution | 1.3 Megapixel |
| Pixel Size | 4.2 µm |
| Sensitivity | 3650 mV/lux‑sec |
| Lens Type | CS‑Mount Aspherical Glass (BCS 019) |
| Aperture | F2.0 |
| Field of View | 112° |
| Focal Length | 19 mm (35 mm equivalent) |
| Focus Distance | Manual 1 cm to ∞ |
| Video Format | AVI, 1280×720 |
| Still Image Format | JPEG, 1280×720 |
| Memory Storage | SD Card up to 32 GB |
| Power Source | 4 AA Batteries or 5 V DC via Micro‑USB |
| DC Input | 5 V via Micro‑USB connector |
| Dimensions (D×W×H) | 64 mm × 52 mm × 107 mm |
| Weight | 140 g (without batteries) |
| Color | Black |
Optional accessories include a weather‑resistant housing (ATH120), Brinno Reader (ABR100), bike cam holder (ABH100), shutter line (ATS110), wall mount (AWM100), motion sensor (ATM110), pan‑lapse unit (ART100), pouch (ATP100), Brinno lenses (BCS 18‑55 & BCS 24‑70), and a micro‑scope adapter (AMH100).
The camera is powered by four AA batteries.
The camera is not waterproof on its own; waterproof operation requires the optional Weather Resistant Housing (ATH120).
