Product manual for Bosch Rexroth CN2 series circular connectors, covering M8, M12, M18, and M23 models with technical specifications and installation data.
This document serves as a product manual for the Bosch Rexroth CN2 series of circular connectors. It details various configurations including male and female plugs for M8x1, M12x1, M18x1, and M23x1 sizes, as well as data termination and Y-connection variants. The manual provides specific technical data for each model, such as environmental temperature ranges, protection ratings (IP65, IP67, IP68), and material compositions. This manual is written in German.
| Temperature Range (M8x1) | -25°C / +80°C |
|---|---|
| Protection Rating (M8x1) | IP 67 |
| Temperature Range (M12x1) | -40°C / +85°C |
| Temperature Range (M23x1) | -25°C / +90°C |
| Protection Rating (M23x1) | IP 68 |
| Outer Shell Material (M8x1) | Polyamide |
| Outer Shell Material (M12x1) | Polyamide |
The maximum operating temperature is +85°C.
